Datenblatt LED-Spiegelrasterleuchte Sylvania RANA LED S 1200 6500LM 4K LOUV+PRI W GEN2.pdf

SYLVANA

RANA LED Surface 1200

RANA LED S 1200 6500LM 4K LOUV+PRI W GEN2

0051491


Product features

  • Surface or Suspended LED luminaire with Louvre + Prismatic Optic, Direct Light Distribution, Luminaire Dimensions: 1160x187x47mm, White body, IP20, IK07, Electric Class 1, Light Engine Dimensions: 1130x165mm, Constant Current, Low LED flicker (+/-5%), Exempt of Photobiologic Risk (RG0), Neutral White (4000K) LED Colour Temperature, 6500lm, 54W, 120lm/W efficacy, CRI>80, 3 SDCM (3-step MacAdam ellipse) LED Colour Consistency, UGR<19, Luminance at 65° < 3000 cd/m2, Lumen Maintenance: L90B10 at 50,000 hours, Quick electrical connection with push-connectors in the luminaire, Glow Wire Test 850°C.

PRODUCT OVERVIEW

LampsYes
Included lampINTEGRATED LED
E-number Finland4273665
ETIM ClassEC002892
TechnologyLED
MountSurface/Suspended
Product nameRANA LED S 1200 6500LM 4K LOUV+PRI W GEN2
Product code0051491
TypeIntegrated LED
HousingSteel
General applicationOffice, Hospitality, Retail, Education,
Electrical protectionCLASS1
Control gear type12
DimmableNo
Total power consumption (W)54
Colour Consistency (SDCM)3
Luminous flux (lm)6500
Colour temperature (K)4000
CRI (Ra)80
Luminous flux mounted (lm)6500
Glare controlUGR<19
ColourWhite
IK ratingIK07
IP ratingIP20
Average Rated Lifetime - L70 B50100000
Product EAN number5410288514918

DATA TABLE

© Feilo Sylvania | Date Printed: 29 Jun 2017 SYLVANIA

RANA LED Surface 1200

RANA LED S 1200 6500LM 4K LOUV+PRI W GEN2

0051491

General data

E-number Finland4273665
ETIM ClassEC002892
TechnologyLED
MountSurface/Suspended
Product nameRANA LED S 1200 6500LM 4K LOUV+PRI W GEN2
Product code0051491
TypeIntegrated LED
HousingSteel
General applicationOffice, Hospitality, Retail, Education,

Optical data

Colour Consistency (SDCM)3
Photobiological Risk Group0
Efficacy (lm/w)120
Luminous flux (lm)6500
Colour temperature (K)4000
CRI (Ra)80
Luminous flux mounted (lm)6500
Glare controlUGR<19

Electrical data

Electrical protectionCLASS1
Control gear type12
DimmableNo
Drive current (mA)275
Control gear requiredNo
kWh per 1000 hours burning time54
Glow Wire Test (°C)850
Lamp power factor0.95
Mains voltage (V)220-240V~
Total power consumption (W)54
Inrush Duration (μs)250
Max. Luminaires per 10A C Breaker21
Max. Luminaires per 16A C Breaker36
Lamp Energy Label (class)A++
Efficacy (lm/w)120
Inrush Current (A)33

Lifetime data

Average Rated Lifetime - L70 B2050000
Average Rated Lifetime - L70 B1050000
Average Rated Lifetime - L80 B5050000

© Feilo Sylvania | Date Printed: 29 Jun 2017 Page 2 of 4 SYLVANIA

RANA LED Surface 1200

RANA LED S 1200 6500LM 4K LOUV+PRI W GEN2

0051491

Average Rated Lifetime - L80 B2050000
Average Rated Lifetime - L80 B1050000
Average Rated Lifetime - L90 B5050000
Average Rated Lifetime - L90 B2050000
Average Rated Lifetime - L90 B1050000
Average Rated Lifetime - L70 B50100000

Physical data

Diffuser finishMicroPrismatic
Diffuser materialPolycarbonate
ColourWhite
Nominal Product Height (mm)47
IK ratingIK07
IP ratingIP20
Weight (kg)3.2
Nominal Product Width (mm)187
Nominal Product Length (mm)1160

Packaging

Packaging outer width (cm)6.5
Packaging outer length (cm)153.5
Packaging outer height (cm)21.0
Packaging single width (cm)6.5
DUN14 (outer)05410288514918
Units per outer package1
Packaging single length (cm)21.0
Single packaging typeCarton
Packaging single height (cm)153.5
Product EAN number5410288514918

© Feilo Sylvania | Date Printed: 29 Jun 2017 SYLVANIA

RANA LED Surface 1200

RANA LED S 1200 6500LM 4K LOUV+PRI W GEN2

0051491


© Feilo Sylvania | Date Printed: 29 Jun 2017 Page 4 of 4
